Alpha Power 3kW

Price: $16,400 AUD

The Alpha Power 3kW is a complete, prefabricated package system that simply plugs together. It is the perfect base system for tiny homes, garages, sheds, workshops, farms, houseboats, cabins, etc.


What's more, the Alpha Power 3kW can be adapted to larger output needs. The system can be expanded to 9kW or 15kW for either a single-phase or three-phase system.

Panel Front On.png
Panel Side on Roof.png
Panel Angled on Roof.png
Box Installed (1).png
Box Open with Battery.png
Box Open with Eletricals.png
Battery Image.png
Panel with Switch.png

What’s Included

  • 6 x 390-watt Trina solar panels complete with ground mounting kit

  • 2 x state-of-the-art Pylontech lithium-ion batteries housed in an IP66 weatherproof rated enclosure

  • Alpha Power 3kW prefabricated control box housed in an IP66 weatherproof rated enclosure including:

    • 3kW Victron inverter charger with a built-in 250V 70A charge controller

    • dual 15A weatherproof power outlets

    • 15A generator input

    • all AC/DC circuit breakers are prewired and ready to plug and play.

  • Wiring looms connect the solar panels to the control box and the control box to the battery pack

  • Comprehensive instruction manual

Specs

    • IP66 weatherproof enclosure

    • Lockable cabinet

    • Floor or Wall mounted

      800mm(h)x600mm(w)x400mm(d)

    • Grey RAL7035 Epoxy UV Resistant

    • 3 x 15A Plugs external ( 2 x output, 1 x input)

    • 1 x Victron Easysolar-II GX/48/3000

    • 6 x 390W Trina Solar Panels

    • 2 x Pylontech Lithium ion batteries

    • DC Input Voltage 38-66V

    • Output Voltage: 240 pure sine wave

    • Frequency: 50Hz +0.1%(1)

    • Cont. output power at 25 degrees celcius (3) 3000VA/2400W

    • Cont. output power at 40 degrees celcius/65 degrees celcius 2200W/1700W

    • Maximum efficiency 95%

    • Max output 24.28A at 122.4 V - 2340 W

    • Dimensions per panel 1754 x 1096 x 30 mm

    • Operational temperature -40+85 degrees celsius

    • Nominal voltage: 48V

    • Total capacity is 7.1kW

    • Total useable capacity s 6.74 kW

    • Max output Power 10kW for 15 sec maximum

    • Cycle life per module - greater than 6000 cycles

    • Expand-ability - up to 80kWh total, adding models and cabinets as necessary at any time (over 5 units in parallel requires a communication hub)

    • Communication: RS485, CAN

    • Charge voltage (V): 52.5-53.5

    • Discharge voltage (V): 45-53.5

    • Working temperature (c): 0-50

    • Shelf Temperature (c) - -20-60

    • Humidity: 5%-85%

    • Warranty: 10 year/6000 cycles

    • Victron connects for Smart Phone Monitoring

    • Optional: internal colour control screen hard-wired or GX LTE 4G or GX GSM remote monitoring and programming
