The Alpha Power system is a prefabricated DIY package that simply plugs together. It is the perfect base system for homes, cabins, sheds, workshops, farms, houseboats, garages, and more.
Make the switch to Solar
Our Alpha range is a complete, easy to install package perfect for homes, cabins, sheds, workshops, farms, and more.
Shop Products
Alpha Power 3kW
Price: $16,400
Alpha Power 5kW
Price: $17,400
Alpha Power 8-10kW
Price: POA
The Alpha solar system is a stand-alone, preassembled energy system that can be used on or off-grid.
Our base Alpha systems are designed specifically for DIY plug-and-play, with comprehensive installation instructions. What's more, they are expandable so as your energy needs change the Alpha series can be adapted to suit.
The Alpha series
Each preassembled energy system is equipped with solar panels, mounting frames, a solar inverter, solar batteries, 15A plugs, all AC/DC circuit breakers prewired, and monitoring technologies. They will keep all your electronics powered, from smartphones, laptops, and lights to AC, refrigerators, washing machines, microwaves, etc.
Compare Products
Alpha Power 3kW
$16,400
-
6 x 390-watt Trina solar panels complete with ground mounting kit
2 x state-of-the-art Pylontech lithium-ion batteries housed in an IP66 weatherproof rated enclosure
Alpha Power 3kW prefabricated control box housed in an IP66 weatherproof rated enclosure with:
3kW Victron inverter charger with a built-in 250V 70A charge controller
dual 15A weatherproof power outlets
15A generator input
all AC/DC circuit breakers pre-wired and ready to plug and play
Wiring looms to connect the solar panels to the control box and the control box to the battery pack
Comprehensive instruction manual
-
IP66 weatherproof enclosure
Lockable cabinet
Floor or Wall mounted
Dimensions: 800mm(h)x600mm(w)x400mm(d)
Finish: Grey RAL7035 Epoxy UV Resistant
3 x 15A Plugs external ( 2 x output, 1 x input)
Victron Easysolar -II GX/48/3000
6 x 390W Trina Solar Panels
2 x Pylontech Lithium ion batteries
-
DC Input Voltage 38-66V
Output Voltage: 240 pure sine wave
Frequency: 50Hz +0.1%(1)
Cont. output power at 25 degrees celsius (3) 3000VA/2400W
Cont. output power at 40 degrees celsius/65 degrees celsius 2200W/1700W
Maximum efficiency 95%
-
(For all 6 solar panels)
Max output 24.28A at 122.4 V - 2340 W
Dimensions per panel 1754 x 1096 x 30 mm
Operational temperature -40+85 degrees celsius
-
(For 2 batteries)
Nominal voltage: 48V
Total capacity is 7.1kW
Total useable capacity s 6.74 kW
Max Output Power 10kW for 15-sec maximum
Cycle life per module - greater than 6000 cycles
Expand-ability - up to 80kWh total, adding models and cabinets as necessary at any time (over 5 units in parallel requires a communication hub)
Communication: RS485, CAN
Charge voltage (V): 52.5-53.5
Discharge voltage (V): 45-53.5
Working temperature (c): 0-50
Shelf Temperature (c) - -20-60
Humidity: 5%-85%
Warranty: 10 years/6000 cycles
-
Victron connects for Smart Phone Monitoring
Optional: internal colour control screen hard-wired or GX LTE 4G or GX GSM remote monitoring and programming
Alpha Power 5kW
$17,400
-
6 x 390-watt Trina solar panels complete with ground mounting kit
2 x state-of-the-art Pylontech lithium-ion batteries housed in an IP66 weatherproof rated enclosure
Alpha Power 5kW prefabricated control box housed in an IP66 weatherproof rated enclosure including:
5kW Victron inverter charger with a built-in 250V 100A charge controller
dual 15A weatherproof power outlets
15A generator input
all AC/DC circuit breakers are prewired and ready to plug and play
Wiring looms to connect the solar panels to the control box and the control box to the battery pack
Comprehensive instruction manual
-
IP66 weatherproof enclosure
Lockable cabinet
Floor or Wall mounted
Dimensions: 800mm(h)x600mm(w)x400mm(d)
Finish: Grey RAL7035 Epoxy UV Resistant
3 x 15A Plugs external ( 2 x output, 1 x input)
1 x Victron Easysolar - II GX/48/5000
6 x 390W Trina Solar Panels
2 x Pylontech Lithium ion batteries
-
DC Input Voltage 38-66V
Output Voltage: 240 pure sine wave
Frequency: 50Hz +0.1%(1)
Cont. output power at 25 degrees celsius (3) 5000VA/4000W
Maximum efficiency 96%
-
(For all 6 solar panels)
Max output 24.28A at 122.4 V - 2340 W
Dimensions per panel 1754 x 1096 x 30 mm
Operational temperature -40+85 degrees celsius
-
(For 2 batteries)
Nominal voltage: 48V
Total capacity is 7.1kW
Total useable capacity s 6.74 kW
Max Output Power 10kW for 15-sec maximum
Cycle life per module - greater than 6000 cycles
Expand-ability - up to 80kWh total, adding models and cabinets as necessary at any time (over 5 units in parallel requires a communication hub)
Communication: RS485, CAN
Charge voltage (V): 52.5-53.5
Discharge voltage (V): 45-53.5
Working temperature (c): 0-50
Shelf Temperature (c) - -20-60
Humidity: 5%-85%
Warranty: 10 years/6000 cycles
-
Victron connects for Smart Phone Monitoring
Optional: internal colour control screen hard-wired or GX LTE 4G or GX GSM remote monitoring and programming
Alpha Power 8kW
Requires consultation
-
Note:
A consultation with our team is recommended so we can create the ideal, bespoke system to meet your energy needs.With that said, the system will typically include:
6 x 390-watt Trina solar panels complete with ground mounting kit
2 x state-of-the-art Pylontech lithium-ion batteries housed in an IP66 weatherproof rated enclosure
Alpha Power 3kW prefabricated control box housed in an IP66 weatherproof rated enclosure with:
3kW Victron inverter charger with a built-in 250V 70A charge controller
dual 15A weatherproof power outlets
15A generator input
all AC/DC circuit breakers are pre-wired and ready to plug and play
Wiring looms to connect the solar panels to the control box and the control box to the battery pack
Comprehensive instruction manual
-
IP66 weatherproof enclosure
Lockable cabinet
Floor or Wall mounted
Dimensions: 800mm(h)x600mm(w)x400mm(d)
Finish: Grey RAL7035 Epoxy UV Resistant
3 x 15A Plugs external ( 2 x output, 1 x input)
8 or 10kW Quattro inverter charger
1 x Victron Smart Solar MPPT 250/100 charge controller
390W Trina Solar Panels and Pylontech Lithium-ion batteries to suit your individual needs
-
Will require a consultation.
-
(For all 6 solar panels however, numbers may vary)
Max output 24.28A at 122.4 V - 2340 W
Dimensions per panel 1754 x 1096 x 30 mm
Operational temperature -40+85 degrees celsius
-
(For 2 batteries however, numbers may vary)
Nominal voltage: 48V
Total capacity is 7.1kW
Total useable capacity s 6.74 kW
Max Output Power 10kW for 15-sec maximum
Cycle life per module - greater than 6000 cycles
Expand-ability - up to 80kWh total, adding models and cabinets as necessary at any time (over 5 units in parallel requires a communication hub)
Communication: RS485, CAN
Charge voltage (V): 52.5-53.5
Discharge voltage (V): 45-53.5
Working temperature (c): 0-50
Shelf Temperature (c) - -20-60
Humidity: 5%-85%
Warranty: 10 years/6000 cycles
-
Victron connects for Smart Phone Monitoring
Optional: internal colour control screen hard-wired or GX LTE 4G or GX GSM remote monitoring and programming
We’re with you each step of the way
Dream it.
It’s time to think bigger and dream up cleaner futures.
Buy it.
Our products come with a generous warranty period, so you can purchase care-free.
Power it.
Our systems can power electronics and utilities, from laptops and lighting to white goods.
Adapt it.
Our systems are designed for adaptability, and can be added to or made hybrid.
Reduce it.
Solar energy contributes to reducing pollution, emissions, and global warming.
Install it.
All systems come with detailed step-by-step assembly instructions.
Discover more about our products and find the answers you've been looking for! Visit our support page now.
