Alpha Power 8kW & 10kW

Price: POA

These are bespoke energy systems that are specifically designed to meet your energy requirements. With either an 8kW inverter or 10kW inverter charger this system is ideal for off grid properties with higher energy needs. A consultation with our team will determine the required number of solar panels and batteries to ensure you have the ultimate energy system. Unlike the Alpha Power 3 & 5kW systems they need to be hard-wired to the customer's switchboard. They can also be joined together to create a 24 or 30kW system for either a single-phase or three-phase system.

Panel Front On.png
Panel Side on Roof.png
Panel Angled on Roof.png
Box Installed (1).png
Box Open with Battery.png
Box Open with Eletricals.png
Battery Image.png
Panel with Switch.png

What’s Included

  • 6 x 390-watt Trina solar panels complete with ground mounting kit

  • 2 x state-of-the-art Pylontech lithium-ion batteries housed in an IP66 weatherproof rated enclosure

  • Alpha Power 8 or 10kW prefabricated control box housed in an IP66 weatherproof rated enclosure including:

    • 8 or 10kW Victron inverter charger with a separate 250V 100A charge controller

    • dual 15A weatherproof power outlets

    • 15A generator input

    • all AC/DC circuit breakers are prewired and ready to plug and play.

  • Wiring looms connect the solar panels to the control box and the control box to the battery pack

  • Comprehensive instruction manual

Specs

    • IP66 weatherproof enclosure

    • Lockable cabinet

    • Floor or Wall mounted

      800mm(h)x600mm(w)x400mm(d)

    • Grey RAL7035 Epoxy UV Resistant

    • 3 x 15A Plugs external ( 2 x output, 1 x input)

    • 1 x Victron 8 or 10kW Quattro inverter charger

    • 1 x Victron Smart Solar 250/100 charge controller

    • 6 x 390W Trina Solar Panels

    • 2 x Pylontech Lithium ion batteries

    • DC Input Voltage 38-66V

    • Output Voltage: 240 pure sine wave

    • Frequency: 50Hz +0.1%(1)

    • Cont. output power at 25 degrees celcius (3) 8000 or 10000VA

    • Cont. output power at 40 degrees celcius 5500W or 6500W

    • Maximum efficiency 95%

    • Max output 24.28A at 122.4 V - 2340 W

    • Dimensions per panel 1754 x 1096 x 30 mm

    • Operational temperature -40+85 degrees celsius

    • Nominal voltage: 48V

    • Total capacity is 7.1kW

    • Total useable capacity s 6.74 kW

    • Max output Power 10kW for 15 sec maximum

    • Cycle life per module - greater than 6000 cycles

    • Expand-ability - up to 80kWh total, adding models and cabinets as necessary at any time (over 5 units in parallel requires a communication hub)

    • Communication: RS485, CAN

    • Charge voltage (V): 52.5-53.5

    • Discharge voltage (V): 45-53.5

    • Working temperature (c): 0-50

    • Shelf Temperature (c) - -20-60

    • Humidity: 5%-85%

    • Warranty: 10 year/6000 cycles

    • Victron connects for Smart Phone Monitoring

    • Optional: internal colour control screen hard-wired or GX LTE 4G or GX GSM remote monitoring and programming
